P0635TXMinarcTig 250 is the ideal DC TIG welding solution for installation, repair and maintenance applications. The 250 amp model suits high-quality work and the lightweight and compact size is a real bonus for professionals on the move around the site.
MinarcTig 250 is a dual-process machine, providing an impressive DC TIG and MMA welding experience. In addition to the basic 250 machine, there is the 250MLP model, equipped with special features, such as Minilog and pulsed arc function. High 35 % duty cycle and lightweight combine real performance advantages, plus exceptional control in low current ignition means refined TIG welding quality for precise applications.
Main Features
- Mains connection voltage 400 V -20...+15 %
- Mains connection phases 3~50/60 Hz
- Mains connection cable type 4G, H07RN-F
- Mains connection cable size 1.5 mm²
- Rated maximum input power [S1max] 8.2 kVA
- Mains fuse 10 A
- Idle power 40 W
- Output, duty cycle % at rated max. current, TIG 30 %
- Output at +40 °C, rated max current, TIG 250 A
- Output at +40 °C, 100% TIG 160 A
- Power factor at rated maximum current [λ] 0.91
- Efficiency at rated maximum current [η] 86 %
- EMC class A
- Minimum short-circuit power of supply network [Ssc] 1.5 MVA
- Welding connection type DIX
- Recommended minimum generator power [Sgen] 15 kVA
- Degree of protection (fully installed) IP23S
- External dimensions, length 400 mm
- External dimensions, width 180 mm
- External dimensions, height 340 mm
- Weight without accessories 10.7 kg
- Standards IEC 60974-1, -3, -10, IEC 61000-3-12
